Nginx

Parsing Nginx Access Log Using Command Line

Parsing-log
mm
Written by Santosh Prasad

My manager ask me to grep some web code to investigate website status. That’s why I need to look nginx access log. After spending more time on internet. I found some command to parsing website access log.
Nginx defaul log format named is “ main” in nginx version: nginx/1.10.1.

log_format  main  '$remote_addr - $remote_user [$time_local] "$request" ' '$status $body_bytes_sent "$http_referer" ' '"$http_user_agent" "$http_x_forwarded_for"';

But unfortunately defaul log format was not sufficient for me. Than I configured nginx to work as a reverse proxy to manage web traffic load. I have configured my custom log format named “upstream “.

log_format upstream  '$http_x_forwarded_for - $remote_user [$time_local] "$request" ''$status $body_bytes_sent "$http_referer" ''"$http_user_agent" "$remote_addr"' 'rt=$request_time ut=$upstream_response_time ''[for $host via $upstream_addr] "$gzip_ratio"';

Here :-

  • $http_x_forwarded_for : Log the real user IP instead of our nginx proxy IP.
  • $remote_user : Most modern app does not use this option for HTTP authenticate with user. It will be blan for most apps.
  • [$time_local] : Logged request time-stamp as per server timezone.
  • “$request” : Request type like- GET, POST, PUT etc.. with args and version.
  • ‘$status $body_bytes_sent’ : Response code generated buy server.
  • “$http_referer”: URL referral
  • rt=$request_time : Response time
  • ut=$upstream_response_time : Upstream response time.
  • $host : Host-name
  • $upstream_addr : Upstream IP address from which request made here our nginx server IP.
  • “$gzip_ratio” : Logged compress ration.

Add the” upstream “parameter at the end of access_log line to tell nginx use custom log format like below :

access_log  /var/log/nginx/vhost/looklinix.com_access.log upstream;

Lets go ahead for parsing nginx access log using command.

List All HTTP Response Status Codes :

# cd /var/log/nginx/
# cat looklinix.com_access.log | cut -d '"' -f3 | cut -d ' ' -f2 | sort | uniq -c | sort

You will get some output like below:

    114 500
  12277 304
    123 416
      1 504
   1614 302
 185148 200
   1892 301
   2188 404
   2508 499
     27 403
     32 401
      3 400
    366 206
    456 502
    477 444
     79 405

Using AWK command :

 # awk '{print $9}' looklinix.com_access.log | sort | uniq -c | sort

You will get some output like below:

    114 500
  12277 304
    123 416
      1 504
   1614 302
 185148 200
   1892 301
   2188 404
   2508 499
     27 403
     32 401
      3 400
    366 206
    456 502
    477 444
     79 405

You can see more than 2000 request returned 404 (Not Found ) response code.

List All Broken (404) Request

Now find out which request are broken and getting 404. We can see all 404 visited page using below command.

 # awk '($9 ~ /404/)' looklinix.com_access.log | awk '{print $7}' | sort | uniq -c | sort -r

You will get some output like below:

      9 /wp-content/uploads/sfn.php
      9 /wp-content/plugins/woocommerce-product-options/includes/image-upload.php
      9 /wp-content/plugins/revslider/temp/update_extract/sfn.php
      9 /wp-content/plugins/revslider/temp/update_extract/revslider/db.php
      9 /wp-content/plugins/revslider/sfn.php
      9 /wp-content/plugins/Login-wall-etgFB/login_wall.php?login=cmd&z3=c2ZuLnBocA%3D%3D&z4=L3dwLWNvbnRlbnQvcGx1Z2lucy8%3d
      9 /wp-content/plugins/jquery-html5-file-upload/jquery-html5-file-upload.php
      9 /wp-content/plugins/formcraft/file-upload/server/php/upload.php
      9 /tiny_mce/plugins/tinybrowser/upload_file.php?folder=/&type=file&feid=&obfuscate=&sessidpass=
      9 /sfn.php
      9 /license.php
      8 /wp-content/uploads/2017/01/mail-client.jpg&_nc_hash=AQCLYYiKAUaGBX1g
      8 /wp-content/plugins/wptf-image-gallery/lib-mbox/ajax_load.php?url=/etc/passwd
      8 /wp-content/plugins/wp-symposium/server/php/index.php
      8 /wp-content/plugins/wp-mobile-detector/cache/db.php
      8 /wp-content/plugins/wp-ecommerce-shop-styling/includes/download.php?filename=../../../../../../../../../etc/passwd
      8 /wp-content/plugins/./simple-image-manipulator/controller/download.php?filepath=/etc/passwd
      8 /wp-content/plugins/recent-backups/download-file.php?file_link=/etc/passwd
      8 /wp-content/plugins/front-end-upload/destination.php
      8 /wp-content/plugins/candidate-application-form/downloadpdffile.php?fileName=../../../../../../../../../../etc/passwd
      8 /wp-content/cache/autoptimize/css/autoptimize_e039f9699b9008b4a87e6e80c5bf48b5.css
      7 /questions/question/php-fpm-and-nginx-502-bad-gateway/
      7 /?p=1602
      7 /author/santosh-prasad/page/4/
      6 /wp-content/uploads/2017/02/web-based-monitoring-tool.jpg&_nc_hash=AQC7GIulBxipvMss
      6 /wp-content/themes/infocus/lib/scripts/dl-skin.php
      6 /wp-content/plugins/simple-ads-manager/js/slider/tmpl.js
      6 /pagead/gen_204?id=
      6 /?p=1894
      6 /?p=1756
      6 /?p=1532
      6 /mdocs-posts/?mdocs-img-preview=../../../wp-config.php
      6 /easy-steps-to-upgrade-php-5-3-to-php-5-6-on-centos-6-x-and-rhel-6-x/http:%5C/%5C/www.looklinux.com%5C/wp-login.php?action=lostpassword
      6 /category/uncategorized/
      5 /wp-content/plugins/google-mp3-audio-player/direct_download.php?file=../../../wp-config.php
      5 /wp-content/plugins/db-backup/download.php?file=../../../wp-config.php
      5 /wp-content/cache/autoptimize/css/autoptimize_b2fab305691e9655969910635d0b8352.css
      5 /sample-page/
      5 /?p=1653

List All 301 Permanently Moved URLs

We can also list all top ten 301 permanently moved URLs using below command.

# awk '($9 ~ /301/)' looklinix.com_access.log | awk '{print $7}' | sort | uniq -c | sort -r | head

You will get some output like below:

      5 /looklinux/preview.php?title=vo7fw
      8 /how-to-run-process-or-program-on-specific-cpu-cores-in-linux
      8 /how-to-access-linux-terminal-using-chrome-web-browser
      8 /easy-steps-to-clone-your-hard-drive-using-dd
      8 /best-5-linux-open-source-text-editors
      8 /awstats/awstats.pl?config=looklinux.com
      7 /top-5-web-based-linux-monitoring-tools
      1 /basic-mysql-commands-database-administrator
      1 /awstats-log-analyzer-installation-and-configuration-on-centos-fedora-and-rhel-system/
      1 /awstats-log-analyzer-installation-and-configuration-on-centos-fedora-and-rhel-system
      1 /author/santosh-prasad/page/2/?ap_ajax_action=search_mentions&%23038;action=ap_ajax

We can also check from which source IP you are 404 request are coming .

# awk -F\” ‘($2 ~ “/survey/report/na”){print $1}’ looklinix.com_access.log | awk ‘{print $1}’ | sort | uniq -c | sort –r

You will get some output like below Command:

3 197.210.28.52,107.167.112.38
2 63.139.29.90
2 175.139.178.106
1 99.95.1.42
1 87.112.31.172
1 86.7.38.59
1 86.163.13.111
1 86.156.51.243
1 86.153.19.27
1 86.149.8.56
1 86.139.199.120
1 86.130.71.225
1 86.129.148.242
1 85.255.235.145
1 85.211.50.44
1 84.51.152.254
1 82.40.13.61 1 82.21.137.68
1 82.15.34.126
1 81.157.121.242 1 81.155.254.63

I hope this article will help to parsing your Nginx log. If you have any queries and problem please comment in comment section.

Thanks:)
